GAONENG GNB 6S 22.2V 3500mAh 70C LiPo Battery XT60
GAONENG GNB 6S 22.2V 3500mAh 70C LiPo Battery XT60 — Energy Reserve for 7-Inch Quads
The GAONENG GNB 6S 22.2V 3500mAh 70C LiPo Battery XT60 is a 6S1P pack for 7-inch FPV drones, EDF jets, 3D planes and 600-700 class helicopters. Its 3500mAh capacity at 22.2V stores 77.7Wh of energy in a 434g pack measuring 36x44x141mm, while a 70C continuous discharge rating (140C burst, roughly 245A continuous) gives it the current headroom for demanding 6S setups, and a standard XT60 connector fits most RC builds. GAONENG lists it as compatible with 7-inch 300-380mm FPV drones, FMS 70mm EDF jets and 1400mm 3D planes, 600-700mm class helicopters such as the Align 600 and T-Rex 600, 800mm warbirds, RC airplanes, multicopters and RC boats, and it can be charged from 1C up to 5C on a compatible balance charger.
GAONENG GNB 6S 22.2V 3500mAh 70C LiPo Battery XT60 Key Features
70C Continuous Discharge
140C burst and roughly 245A of continuous current for demanding 6S setups.
XT60 Connector
Direct drop-in compatibility with the XT60 standard used across most RC platforms.
1C-5C Charging
Supports fast charging up to 5C on a compatible balance charger.
77.7Wh in 434g
3500mAh at 22.2V for longer sessions on 7-inch quads and larger models.
GAONENG GNB 6S 22.2V 3500mAh 70C LiPo Battery XT60 Suitable Applications
GAONENG lists the following applications for this pack:
- 7-inch 300-380mm FPV drones
- FMS 70mm EDF jets and 1400mm 3D planes
- 600-700mm class helicopters, including the Align 600 and T-Rex 600
- 800mm warbirds
- RC airplanes and multicopters
- RC boats and general RC hobby use
- Before use, the battery must be fully charged.
- Only use a charger designed for lithium-polymer/lithium-ion batteries and never leave the battery unattended during the charging process.
- When charging, always keep the battery away from flammable and explosive materials.
- Never overcharge the battery. The maximum voltage for a LiPo battery is 4.2V per cell, and for a LiHV battery, it is 4.35V per cell.
- Never discharge the battery below 3V per cell under load.
- Fully charged batteries should not be stored for more than 3 days. For long-term storage, maintain a voltage between 3.8V and 3.9V.
- Do not disassemble, crush, short-circuit, or expose to flames or other ignition sources.
- Do not use batteries that are deformed or swollen.
GAONENG GNB 6S 22.2V 3500mAh 70C LiPo Battery XT60 Dimensions
GAONENG GNB 6S 22.2V 3500mAh 70C LiPo Battery XT60 Specification
Model | GNB35006S70A |
Cell Configuration | 6S1P |
Nominal Voltage | 22.2V (25.2V fully charged) |
Capacity | 3500mAh |
Energy | 77.7Wh |
Discharge Rate | 70C continuous, 140C burst (approx. 245A) |
Charge Rate | 1C to 5C |
Discharge Connector | XT60 |
Dimensions | 36x44x141mm (HxWxL) |
Weight | 434g (+/-13g) |
GAONENG GNB 6S 22.2V 3500mAh 70C LiPo Battery XT60 Package Includes
- 1x GAONENG GNB 6S 22.2V 3500mAh 70C LiPo Battery XT60
- 1x User Instructions
