Tattu TA1000 G-Tech Dual-channel Charger
The Tattu TA1000 G-Tech Dual-channel Charger takes the hassle out of looking after big drone packs. Plug in a G-Tech battery and the charger sets itself up, so you spend less time in menus and more time in the air. Two independent channels, a clear screen and a compact case with a handle make it an easy companion both in the workshop and out in the field.
Tattu TA1000 G-Tech Dual-channel Charger — Charging and Storage Made Simple
The Tattu TA1000 G-Tech Dual-channel Charger is a 1000W smart charger for LiPo and LiHV drone batteries from 1S to 7S. It has two independent channels, each delivering up to 500W and 25A, with XT90 output connectors. Connected to a G-Tech battery through its smart balance connector, it recognises the battery type and voltage and sets the 1C charging current recommended by the battery manufacturer on its own; non-G-Tech batteries are charged with manually selected battery type, current and mode. Besides normal charging it has a storage mode that brings a pack to storage voltage, and in its 186x174x95mm case it weighs about 1.7kg.
Tattu TA1000 G-Tech Dual-channel Charger Key Features
- Intelligent recognition with G-Tech technology
- Two channels with fully independent functions
- Compact and flexible, with 25A charging current
- LiPo/LiHV 1-7S (supports G-Tech and non-G-Tech batteries)
Automatic Battery Identification Thanks to G-Tech
When connected to a G-Tech battery, the TA1000 charger seamlessly identifies the battery type and voltage through the smart balance connector. It then automatically assigns the recommended 1C charging current specified by the battery manufacturer. For non-G-Tech batteries, you can manually select the battery type, charging current and operating mode.
The TA1000 has a comprehensive charging capacity display, voltage difference monitoring and IR detection, all in a compact, lightweight case that is easy to carry. The wide-view IPS display makes it comfortable to use, and the charger supports high-power charging of up to 25A.
Multi-Level Protection
The charger offers a full set of protections: over-temperature, over-current, over-charge, over-voltage, disconnection, short circuit, single-cell low voltage and reverse polarity protection. It works in two modes, charge and storage. During charging, real-time monitoring tracks the battery status closely and stops charging automatically when the battery reaches full capacity.
Intuitive Operation
The new, intuitive user interface is designed for simplicity, so battery management is a hassle-free task for users at every level.
Tattu TA1000 G-Tech Dual-channel Charger Specification
Input Voltage | AC 100-240V 50/60Hz |
Output Voltage | DC 0-32V |
Channels | 2 (independent) |
Charging Current | Max. 25A x2 |
Charging Current in Storage Mode | 25A x2 |
Discharge Current in Storage Mode | 6A x2 |
Maximum Charging Power | 500W x2 |
Maximum Charging Power in Storage Mode | 500W x2 |
Maximum Discharge Power in Storage Mode | 70W x2 |
Output Connector | XT90 |
Supported Batteries | LiPo/LiHV 1-7S (G-Tech smart balance connector and non-G-Tech batteries) |
Working Temperature | 0-60°C |
Storage Temperature | -20 to 60°C |
Dimensions | 186x174x95mm |
Weight | Approx. 1.7kg |
Tattu TA1000 G-Tech Dual-channel Charger Package Includes
- 1x Tattu TA1000 G-Tech Dual-channel Charger
- 1x AC Power Cable
- 1x USB Cable
- 1x User Manual
